Drawing coming soon
| A - Hub Center To Flange Center, Non-Drive Side (mm) | 44.8 |
|---|---|
| B - Hub Center To Flange Center, Drive Side (mm) | 28.9 |
| C - Axle Width (mm) | LEFTY |
| Spoke Hole Circle Diameter, Drive Side (mm) | 42.0 |
| Spoke Hole Circle Diameter, Non-Drive Side (mm) | 57.0 |
| Spoke Hole Counts Available | 32 |
| Weight | 5.7 oz / 162 g |
|---|---|
| Dimensions - Approximate for Shipping | 9.5 × 4.5 × 4 in |
| Hub Type | |
| Hub Spacing | |
| Axle Width - mm | |
| Spoke Count | |
| Attach Style | |
| Hub Shell Style | |
| Hub Shell Flange Type | |
| Disc Brake Rotor Mount | |
| Spoke Tension - Max kgf | |
| Product Line |
| Although we do our best to ensure these values are correct, always verify by measurement. Onyx Racing takes no responsibility for errors. | ||
| Results for an ERD of 0 mm | ||
| 32 Spoke Holes | Non-Drive Side (mm) | Drive Side (mm) |
|---|---|---|
| 1-Cross | 0 | 0 |
| 2-Cross | 0 | 0 |
| 3-Cross | 0 | 0 |
| 4-Cross | 0 | 0 |
| Image | Name | Qty Per | SKU | Price |
|---|---|---|---|---|
 | Axle Cap | 1 | 083992 | $10.00 - $25.00 depending on selected option |
 | Bearing, Ceramic Hybrid - 6805 - 25 x 37 x 7 | 1 | 038495 | Original price was: $42.00.$31.50Current price is: $31.50. |
 | Bearing, Ceramic Hybrid - 6902 - 15 x 28 x 7 | 1 | 038106 | Original price was: $28.00.$21.00Current price is: $21.00. |
 | Bolt, Axle - Lefty | 1 | 098779 | $5.00 |
 | O-Ring, 8 mm x 2 mm | 1 | 083989 | $0.25 |
 | Washer, Flat - Nylon 0.45 id x 0.65 od x .015 thk | 1 | 083990 | $2.00 |
 | Washer, Flat - Nylon 1.06 id x 1.45 od x .040 thk | 1 | 083991 | $2.00 |
