Onyx TRACK 130/10mm Bolt-on Helix Rear Hub

SKU: 084054-Helix Category:

Description and Drawings

SKU: 084054-Helix
SKU: 084054-Helix
A - Hub Center To Flange Center, Non-Drive Side (mm) 35.72
B - Hub Center To Flange Center, Drive Side (mm) 35.72
C - Axle Width (mm) 130
Spoke Hole Circle Diameter, Drive Side (mm) 67
Spoke Hole Circle Diameter, Non-Drive Side (mm) 67
Spoke Hole Counts Available 24/32

Specs

Weight 8.9 oz / 252 g
Dimensions - Approximate for Shipping 9.5 × 4.5 × 4 in
Hub Type

Axle Width - mm

Axle Diameter - mm

Spoke Count

,

Attach Style

Hub Shell Style

Hub Shell Flange Type

Bolts

Driver Style

Spoke Tension - Max kgf

Product Line

Onyx TRACK 130/10mm Bolt-on Helix Rear Hub

  • Please enter a number from 100 to 999.
  • This field is for validation purposes and should be left unchanged.

Although we do our best to make sure these spoke length values are correct, it is always best to measure the hub and verify these values for yourself!  Onyx Racing takes no responsibility for errors in these calculations.

Spoke length results for an ERD of 0 mm
24 Spoke HolesNon-Drive Side
(mm)
Drive Side
(mm)
1-Cross 00
2-Cross 00
3-Cross 00
4-Cross 00
32 Spoke HolesNon-Drive Side
(mm)
Drive Side
(mm)
1-Cross 00
2-Cross 00
3-Cross 00
4-Cross 00

Parts for Onyx TRACK 130/10mm Bolt-on Helix Rear Hub

ImageNameQty PerSKUPrice
Onyx Axle, Rear - TRACK 084019 Onyx Logo in Red
Axle, Rear - TRACK1084019-logo$25.00
Onyx Bearing, Ceramic Hybrid - 6902 - 15 x 28 x 7 038106
Bearing, Ceramic Hybrid - 6902 - 15 x 28 x 72038106$28.00
Onyx Bolt, SOC HD 10mm x 1.5pitch x 40mm, Titanium 084166
Bolt, SOC HD 10mm x 1.5pitch x 40mm, Titanium2084166$20.00
Onyx Bolt, SOC HD 3mm x 8mm, Stainless Steel 042557
Bolt, SOC HD 3mm x 8mm, Stainless Steel1042557$0.25
Onyx Cone, Knurled - 10mm 100384 in Red
Cone, Knurled - 10mm2100384$10.00
Onyx Nut, Locking - 15mm 083579 in Red
Nut Kit, Locking - 15mm1091044$20.00
Onyx O-Ring, 12 mm x 2 mm 088073
O-Ring, 12 mm x 2 mm2088073$0.25
Onyx Retaining Ring, Internal 28mm bore 040216
Retaining Ring, Internal 28mm bore2040216$1.00
